-limited type anti-vibration mount.
-This product can be used when the operation weight of equipment shall be increased and different from stop weight.
-Adjusting optimized height level.
-Easy to adjust level by control bolt.
-Attached Neoprene Pad in order to avoid structure borne-noise
transmission.
-One side of Neoprene Pad is cut for drain to prevent product corrosion.

-Upper part steel plate
-Temporary strut
-Control bolt
-Upper part spring cap
-Coil spring
-Lower part spring cap
-Lower part steel plate
-Neoprene Pad​

​
